   Products  Installation material  Junction boxes  Plastic  KA  KA 012

KA 012 WH

Junction box 86x86x41mm, plastic, RAL 9001

Products may differ in size, colour and appearance to those shown. If you require further information or customisation, please contact us directly.

Features

Logo Logo
Material Polyethylene / Polypropylene
Protection class IP55
Temp. range min -30 °C
Temp. range max 60 °C
Temperatures during install. -5 °C - 60 °C
Glow wire test 750 °C
Voltage 400 V
Rated cross section 4 mm²
Fixing 2 external mounting feet
Ø cable diameter min 7 mm
Ø cable diameter max 12 mm
External dimensions LxWxH 86 x 86 x 41 mm
Using for cable gland Using for cable gland
Product Color RAL 9001
Order no. RAL 9001 10109589
Type KA 012 WH
Packing unit 10
EAN number 4007686094961
Tariff number 39269097
ETIM-Classification EC002600
Remarks:

Fixture: with cable ties, 2 external mounting feet
Equipment: 12 self-sealing, cutable cable entries at the side, 4 on the bottom
captive cover
